ENGINE SPECIFICATIONS

• GX200 Honda air cooled engine
• Single cylinder, 4-stroke gasoline engine
• Manual recoil start
• 0.8 gallon (3.1 l) integrated fuel tank

INCLUDED ACCESSORIES

• Low oil alert
• PUMP UNIT SPECIFICATIONS
• C.E.T. dual stage centrifugal pump
• Pump body made from aluminum
• Aluminum impeller
• Mechanical shaft seal
• Self priming system
• Two 1 (25 mm) delivery outlets and one 1 1 ⁄2 (38 mm) NPSH delivery outlet
• One 1 1 ⁄2 (38 mm) NPSH suction inlet
• Dimensions (approx.): Length: 19 (483 mm) Width: 17 (406 mm); Height: 16 (381 mm)
• Weight (approx.): 59 lbs (27 kg)

70 GPM @ 12 PSI
65 GPM @ 50 PSI
45 GPM @ 100 PSI
45 GPM @ 125 PSI
